Description

Caterpillar 352 excavator

Machine Specifications

• Operating Weight: 50,300 kg
• Engine Model: Cat C13
• Net Power: 311 kW
• Maximum Digging Depth: 7.06 m
• Maximum Reach at Ground Level: 11.62 m
• Maximum Cutting Height: 10.99 m
• Maximum Loading Height: 7.37 m
• Maximum Vertical Wall Depth: 5.35 m
• Bucket Capacity Range: 2.2–3.0 m³

Engine

• Engine Model: Cat C13
• Net Power: 311 kW
• Emissions: Meets applicable global emissions standards
• Cooling: High‑capacity cooling system for continuous heavy‑duty operation

Hydraulic System

• Main System – Maximum Flow: 770 L/min
• Maximum Pressure – Equipment: 35,000 kPa
• Maximum Pressure – Travel: 35,000 kPa
• Maximum Pressure – Swing: 28,000 kPa
• Hydraulic Tank Capacity: 115 L

Swing System

• Swing Speed: 7.5 rpm
• Swing Torque: 164 kN·m

Travel & Undercarriage

• Maximum Travel Speed: 4.6 km/h
• Drawbar Pull: 338 kN
• Track Gauge: 2.74 m
• Track Length: 5.49 m

Service Refill Capacities

• Fuel Tank: 820 L
• Cooling System: 60 L
• Engine Oil: 36 L
• Swing Drive: 18 L
• Final Drives (each): 5 L

Dimensions (Standard Boom & Stick)

• Transport Length: 12.22 m
• Transport Width: 3.34 m
• Transport Height: 3.77 m
• Tail Swing Radius: 3.75 m

Technology & Safety

• Cat Grade 2D / 3D options
• Cat Payload system
• E‑Fence safety boundaries
• ROPS cab
• Rear‑view and side‑view cameras

For more information, please get in contact with us on 01473 612761 or email us at [email protected]
